| Electrical Characteristics | |
| Nominal Voltage | 12.8V |
| Nominal Capacity | 300Ah @ 0.2C |
| Energy | 3840Wh |
| Internal Resistance | ≤ 35mΩ |
| Cycle Life | 4000-6000 Cycles @ 0.2C Charging/Discharging, Until 70% Capacity |
| Self Discharge | ≤ 3.5% per month at 25°C |
| Standard Charging | |
| Max. Charging Voltage | 14.0 ~ 14.6V |
| Charging Mode | At 0°C ~ 45°C temperature, charged to 14.6V at a constant current of 0.2C, and then, changed continuously with constant voltage of 14.6V until the current was not more than 0.02C |
| Charging Current | 100A |
| Max. Charging Current | 100A |
| Standard Discharging | |
| Discharging Current | 150A |
| Max. Continuous Current | 150A |
| Max. Pulse Current | 300A (< 3S) |
| Discharging Cut-off Voltage | 10.0V |
| Operating Condition | |
| Charge Temperature | 0°C to 45°C (32°F to 113°F) @ 60±25% Relative Humidity |
| Discharge Temperature | -20°C to 60°C (-4°F to 140°F) @ 60±25% Relative Humidity |
| Storage Temperature | 0°C to 45°C (32°F to 113°F) @ 60±25% Relative Humidity |
| Water Dust Resistance | IP55 |
| Structure | |
| Cell & Format | LFP72H4K0 (4S1P), prismatic |
| Casing | Plastic |
| Dimension (L*W*H*TH) | 522 * 238 * 217 * 217 mm |
| Weight | Approx. 27.5Kg |
| Terminal | M8 |
