| Specification Parameter | Unit | Value / Details |
|---|---|---|
| Transfer Switch | A | 60 |
| Max AC Input | A | 60 |
| Inverter Parameters | ||
| Output Frequency and Voltage | - | 50/60Hz: L/N/PE 220/230V |
| Rated AC Output and UPS Power | W | 12000 |
| Max AC Output Active Power | W | 13200 |
| Peak Power 10s | W | 24000 (10 Seconds) |
| Max AC Output Current (A) Maximum | A | 57.4 |
| Max Efficiency | - | 97.60% |
| Charging Parameters | ||
| Max Charging Current | A | 250 |
| Max Discharging Current | A | 250 |
| Solar Input | ||
| Max PV Input Power | W | 15600 |
| Max Open Circuit Voltage | V | 500V |
| MPPT Efficiency | - | >99% |
| MPPTs Range | V | 150 ~ 430 |
| Battery Specifications | ||
| Rated Voltage | V | 51.2 |
| Rated Capacity (Single) | Wh | 5120 Wh multiplied by number of modules |
| Usable Capacity (Single) | Wh | 4966 Wh multiplied by number of modules |
| Max No. Modules | - | 8 |
| Max Capacity | kWh | 40.96 |
| Working Temperature | - | Charging: 0~65°C / Discharging: -20~65°C |
| Design Life | - | 10+ Years |
| Cycle Life | - | >6000 Cycles |
| Authentication Level | - | IEC62619 / CE / UN38.3, IEC/EN 61000-6-1, IEC/EN 61000-6-2, IEC/EN 61000-6-3, IEC/EN 61000-6-4 |
| Warranty | - | 10 Years to 80% retention |
